| 商品編號： | CAM2281 | |
| 商品名稱： | Applied Flow Technology Arrow v4.0.2012.05.04 | | | 語系版本： | 英文正式版 | |
| 商品類型： | 供易於使用的，全面的，可壓縮的管道流體分析和系統應力模型軟體 | |
| 運行平台： | Windows XP/Vista/7 | |
| 更新日期： | 2012-11-09 | |
| 光碟片數： | 1片CD光碟 | |
| 銷售價格： | $100元 | |
| 熱門標籤： | 系統應力模型軟體
可壓縮的管道流體分析
Arrow
Applied
| |
Applied Flow Technology Arrow v4.0.2012.05.04 英文正式版(供易於使用的，全面的，可壓縮的管道流體分析和系統應力模型軟體)
關掉主程式,破解檔放置於crack夾內,請將破解檔複製於主程式的安裝目錄內既可破解
能夠提供易於使用的，全面的，可壓縮的管道流體分析和系統應力模型。面向開放和閉合循
環系統，包括內建的流體靜力學和設施庫，大量成型的模型，風扇、壓縮機模型和控制閥模
型等。
AFT Arrow 4.0 provides comprehensive, compressible
pipe flow analysis and system modeling capabilities
combined with ease-of-use. Addressing open and
closed loop systems, AFT Arrow includes a built-in
library of fluids and fittings, variable model
configurations, fan/compressor and control valve
modeling and much more. With the optional Chempak
add-in, a thermo-physical database of approximately
600 gases is available to further expand the
envelope of your analysis and design. AFT Arrow goes
beyond the boundaries of fluid flow analysis, with
thermal analysis capabilities including piping heat
transfer, heat exchanger modeling and varying fluid
properties.
Extend AFT Arrow's modeling capabilities with two,
available Add-on Modules:
* GSC-Goal Seek and Control to automate the
determination of input parameters that will yield
desired output values and simulate control
functions within systems
* CST-CoST calculations of pipes and components
AFT Arrow employs a robust solver using proven
matrix methods to solve the governing equations of
pipe flow to conduct a true and rigorous
compressible flow solution. AFT Arrow is unique in
its ability to solve for adiabatic, isothermal and
generalized heat transfer conditions and with sonic
choking. The full power of this technical
sophistication is readily accessible through an
advanced visual interface. From the powerful
drag-and-drop model building features to the fully
customizable output, AFT Arrow becomes an extension
of the engineer's mind, freeing him or her to focus
on their system, not the mechanics of software
manipulation.
More than flow analysis, AFT Arrow lets you build
your piping system in software. Vary pipe sizes,
compressor/fan curves, valve settings, fluid
properties, operating lineup...virtually anything
you can do with the real system can be done within
AFT Arrow, accurately simulating the individual
system components and their interaction. Whether
you're designing new systems, modifying existing
ones or analyzing system operations, The ability to
analyze alternates and the insight provided by an
AFT Arrow model significantly improves the quality
of systems engineering you can achieve, leading to
less costly, more efficient and more reliable piping
systems.
|
